Piston Air Compressor for Hardware Store (Direct Driven Air Pump, 100% copper)
Power | 1HP/850W | 2HP/1500W | 3HP/1250W | 3.5HP/1150W | 4HP/1500W | 5HP/1350W | 6HP/2200W |
Voltage | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz | 220v/50hz |
Exhaust Pressure | 0.8Mpa | 0.8Mpa | 0.8Mpa | 0.8Mpa | 0.8Mpa | 0.8Mpa | 0.8Mpa |
Current | 4.5A | 7.5A | 6A | 6A | 7.5A | 7.0A | 10.5A |
Revolving Speed | 2850rpm | 2850rpm | 2850rpm | 2850rpm | 2850rpm | 2850rpm | 2850rpm |
Air Tank Volume | 9L | 30L | 30L | 35L | 40L | 50L | 50L |
Cylinder | 1x42mm | 1x47mm | 1x47mm | 1x48mm | 1x51mm | 1x51mm | 2x47mm |
length of power line | 1.5m | 1.5m | 1.5m | 1.5m | 1.5m | 1.5m | 1.5m |
Air Delivery | 137L/min | 200L/min | 188L/min | 198L/min | 235L/min | 235L/min | 356L/min |
air tank size | 360x160mm | 480x240mm | 480x240mm | 480x240mm | 545x260mm | 545x280mm | 550x280mm |
upper air time | 53seconds | 72seconds | 72seconds | 68seconds | 80seconds | 100seconds | 60seconds |
Carton Size | 48x19x48cm=0.04m3 | 61x25.5x59cm=0.09m3 | 61x25.5x59cm=0.09m3 | 61x25.5x59cm=0.09m3 | 69x28x60cm=0.12m3 | 71x29x59cm=0.12m3 | 71x29x59cm=0.12m3 |
GW/NW | 15/14kgs | 24/22kgs | 24/22kgs | 24/22kgs | 29/27kgs | 31/29kgs | 34/32kgs |
1*20GP QTY | 484PCS | 288PCS | 288PCS | 216PCS | 180PCS | 171PCS | 171PCS |
1*40HQ QTY | 1500PCS | 684PCS | 684PCS | 684PCS | 544PCS | 492PCS | 492PCS |
