Industrial Used Piston Air Compressor (Power: 380v/3ph, belt driven/air cooling)
Air Displacement | Exhaust Pressure | Power | No. Of Cylinder (pcs)×Dia | Rotating Speed | Tank Capacity | N.W | Dimension L×W×H | |||
m3/min | cfm | Mpa | psig | KW | HP | mm | rpm | L | KG | mm |
0.4 | 14.1 | 0.7 | 102 | 3 | 4 | 3×70 | 860 | 120 | 200 | 1340×470×980 |
0.55 | 19.4 | 0.7 | 102 | 4 | 5.5 | 3×70 | 1050 | 170 | 215 | 1360×510×1020 |
0.75 | 26.5 | 0.7 | 102 | 5.5 | 7.5 | 2×100 | 830 | 250 | 285 | 1670×500×1090 |
1.05 | 37.1 | 0.7 | 102 | 7.5 | 10 | 3×100 | 820 | 320 | 335 | 1690×530×1260 |
1.55 | 54.8 | 0.7 | 102 | 11 | 15 | 2×125,1×110 | 830 | 320 | 487 | 1740×590×1350 |
2.15 | 76 | 0.7 | 102 | 15 | 20 | 2×125,1×110 | 830 | 500 | 582 | 1840×640×1460 |
0.3 | 10.6 | 1.25 | 181 | 3 | 4 | 2×70,1×55 | 880 | 170 | 200 | 1340×470×980 |
0.38 | 15.0 | 1.25 | 181 | 4 | 5.5 | 2×70,1×55 | 1050 | 170 | 225 | 1360×510×1020 |
0.65 | 21.2 | 1.25 | 181 | 5.5 | 7.5 | 2×100,1×80 | 710 | 250 | 305 | 1670×500×1090 |
0.9 | 28.3 | 1.25 | 181 | 7.5 | 10 | 2×100,1×80 | 950 | 320 | 335 | 1690×530×1260 |
1.20 | 40.6 | 1.25 | 181 | 11 | 15 | 2×125,1×100 | 760 | 320 | 487 | 1740×590×1350 |
1.70 | 58.3 | 1.25 | 181 | 15 | 20 | 2×125,1×100 | 760 | 500 | 582 | 1840×640×1460 |
