Drill Hole Depth

30m

Suitable Bore Rod Size

Φ76*3m, Φ89*3m

Diesel Motor

YC4D100-T310 (D8LFG5)

Diesel Motor Power

73.5kw, 2200r/min

Max torque of gyration head

3200Nm

Speed of gyration head

0~70rpm

Propeller Total Length

6702mm

Pushing Method

Oil Cylinder+Chain Driven

Pushing Stroke

4000mm

Pushing Compensation Length

1200mm

Max Pushing Force

12kN

Max Lifting Force

20kN

High Speed Walking (Max Speed)

3.5km/h

Low Speed Climbing (Max Speed)

2.2km/h

Climbing Capacity

25° (Max 30°)

Crawler Frame Swing Angle

±10°

Ground Clearance

360mm

Max Rotation Angle of the Slide Frame

145°

Max Swing Angle of the Slide Frame

Left: 20°; Right: 91°

Drill Arm Max Pitching Angle

Upper: 50°; Down: 20°

Drill Arm Max Horizontal Swing Angle (°)

Left: 45°; Right: 45°

Weight

7600kg

Transportation Size

L 7372*W 2260*H 2800mm
