◇High pressure two stage compression variable speed screw air compressor (30-40bar, water cooling)
Model | Motor Power (kw/hp) | Pressure (bar) | Air Flow (m3/min) | Cooling Method | Dimension (mm) |
HPT75V-W40 | 75/100 | 40 | 6.3 | water cooling | 2550*1660*1800 |
HPT90V-W40 | 90/125 | 40 | 7.4 | water cooling | 2550*1660*1800 |
HPT110V-W40 | 110/150 | 40 | 9.1 | water cooling | 2990*1850*1900 |
HPT132V-W40 | 132/180 | 40 | 10.2 | water cooling | 2990*1850*1900 |
HPT160V-W40 | 160/215 | 40 | 12.5 | water cooling | 2990*1850*1900 |
HPT200V-W40 | 200/270 | 40 | 16 | water cooling | 4000*2000*2100 |
HPT250V-W40 | 250/340 | 40 | 20.1 | water cooling | 4000*2000*2100 |
HPT75V-W30 | 75/100 | 30 | 7.2 | water cooling | 2550*1660*1800 |
HPT90V-W30 | 90/125 | 30 | 9.1 | water cooling | 2550*1660*1800 |
HPT110V-W30 | 110/150 | 30 | 10.2 | water cooling | 2900*1850*1900 |
HPT132V-W30 | 132/180 | 30 | 12.5 | water cooling | 2900*1850*1900 |
HPT185V-W30 | 185/250 | 30 | 16.0 | water cooling | 2900*1850*1900 |
HPT225V-W30 | 225/300 | 30 | 20.1 | water cooling | 4000*2000*2100 |
